Description
Sensor
Resolution(pixel)
2560×1440
Sensitivity(lux)
0.001
Frame Rate(fps)
60/30
Optics
Objective Lens(mm)
22.5
Optical Magnification(x)
4
Digital Zoom(x)
1-3.5
Continuous Digital Zoom
4/28
Field of View (Horizontal)
22°
Field of View (Vertical)
12
Field of View (Diagonal)
25°
Eye Relief(mm)
25
Diopter Adjustment(D)
±5
Focus Range(cm)
3-∞
Adaptor Diameter(mm)
45/48
IR Illuminator
IR Type
VCSEL
IR Power(W)
5
IR Illuminating Level
3 levels
IR Distance(m)
350
IR Wavelength(nm)
850/940
Display
Type
OLED
Resolution(pixel)
1024*768
Color Mode
Color/Black/White
Photo / Video
Photo Resolution(pixel)
2592*1944
Photo Format
.JPG
Video Resolution(pixel)
1920*1080
Video Format
.mp4
Storage(GB)
TF card (Max. 128GB)
Main Function
LRF Detection Range(yds)
1200
Red Dot
Yes
Self-activated Recording
Yes
Auto Recording
Yes
Loop Recording
Yes
Time Stamp
Yes
Record Audio
Yes
Beep Sound
Yes
Exposure Compensation
Yes
Interfaces
USB Type-C
Yes
HDMI Output
Yes
Connections
WiFi
Yes
Supported Apps
PardVision
Power Supply
Battery Type
18650 Li-ion Battery
Output Voltage(V)
3.7
Operating Time(h,max)
≤8
External Power Supply(V)
USB Type-C
Environmental Characteristic
Integration of Protection
IP67
Operating Temp(°C/°F)
-20 ~ +40
Recoil Resistance(J)
6000
Material
Housing
AL6061 + Plastic
Objective Lens
Glass
Measurement
Product Dimension(L x W x H, mm)
105*120*71(without eye cap)/105*134*71(with cap)
N.W/pcs(with/without Battery, g)
335g(Standard version)/355g(LRF version)
