Description
DUE TO THE WEIGHT AND SIZE OF THE PRODUCT WE ARE GOING TO SEND YOU A QUOTE ON SHIPPING BASED ON YOUR AREA
SPECIFICATIONS
Nominal Voltage 25.6V
Nominal Capacity 100Ah (at rate of 1C)
Energy 2.56kWh (at rate of 1C)
Max Current 100A
Boost / Absorption Voltage 28.8V
Float Voltage 28V
Discharge cut-off Voltage 22.4V DC
* LCD Display Screen
• Over-discharge protection. • Over-charge protection. • Temperature protection. • Short Circuit Protection. BUILT-IN PROTECTION
• Parallel connection is optional. • Battery rack or cabinet is optional.
Operating Temperature Warranty
DoD
Zero to 50°C 10 years or 3 500 cycles at 1 cycle per day When used properly every day the can be safely discharged to 100% of its rated 100Ah capacity. Battery life is shortened if it is discharged beyond 100Ah.
