Description
More Parameters
Input voltage:AC 110V/220V 50/60Hz
Output voltage:0 ~ 30V /60V
Output current:0 ~ 5A/10A
Voltage resolution:10mV
Current resolution:1mA
Output Voltage ranges from 0 to rating voltage with continuous adjustment .
Voltage regulation : Line regulation<5mV. Load regulation<5mV.
Recovery time<500us(50% Load change, minimum load 0.5A)
Ripple & Noise<5m Vrms, 100m Vp-p
Temperature coefficient<100p pm/C.
Output current ranges from 0 to rating current with continuous adjustment
Current regulation line regulation<3mA. load regulation<3mA.
Indicator Meter
Voltage display precision: +-(0.5% of rdg + 2 digits).
Current display precision: +-(0.5% of rdg + 2 digits).
Operation Temperature & Humidity : 0 ~ 40 C, RH<80%.
Storage Temperature & Humidity : -10 ~ 70 C, RH<70%. DC Power Supply Advantage 1.Have complete operating protection function
2.Highly efficient, low ripple, small volume, light weight
3.Double display voltage, current, and high precision
4.Voltage stabilization, current limiting, simple operation
5.Dual voltage input and convenient choice
6.Temperature control fan heat dissipation, low noise
7.Double potentiometer more precise adjustment
8.4-digits LED Screen Display(GPS Series)
Output voltage:0 ~ 30V /60V
Output current:0 ~ 5A/10A
Voltage resolution:10mV
Current resolution:1mA
Output Voltage ranges from 0 to rating voltage with continuous adjustment .
Voltage regulation : Line regulation<5mV. Load regulation<5mV.
Recovery time<500us(50% Load change, minimum load 0.5A)
Ripple & Noise<5m Vrms, 100m Vp-p
Temperature coefficient<100p pm/C.
Output current ranges from 0 to rating current with continuous adjustment
Current regulation line regulation<3mA. load regulation<3mA.
Indicator Meter
Voltage display precision: +-(0.5% of rdg + 2 digits).
Current display precision: +-(0.5% of rdg + 2 digits).
Operation Temperature & Humidity : 0 ~ 40 C, RH<80%.
Storage Temperature & Humidity : -10 ~ 70 C, RH<70%. DC Power Supply Advantage 1.Have complete operating protection function
2.Highly efficient, low ripple, small volume, light weight
3.Double display voltage, current, and high precision
4.Voltage stabilization, current limiting, simple operation
5.Dual voltage input and convenient choice
6.Temperature control fan heat dissipation, low noise
7.Double potentiometer more precise adjustment
8.4-digits LED Screen Display(GPS Series)
